1212FCA
제품사양
| Sensor Type | IGZO TFT |
|---|---|
| Scintillator | CsI |
| Total Pixel Matrix (Pixels) | 1536 x 1536 pixels |
| Active Area (mm) | 298 x 298 mm |
| Pixel Pitch (㎛) | 194 ㎛ (@1x1) |
| A/D Conversion (bits) | 14/16 bits |
| Data Interface | GigE |
| Frame Rate (fps) | Normal mode (1536 X 1536) : 24 (1x1) / 48 (2x2) |
| Energy Range (kVp) | 40 - 150 kVp |
| Dimension (mm) | 334 x 326 x 49.8 mm |
| Weight (kg) | - |
| Resolution (lp/mm) | - |
